RocketMQ k8s部署 4主4从集群

RocketMQ k8s部署 4主4从集群

使用NFS配置StatefulSet的动态持久化存储

安装NFS服务端

1
2
sudo apt update
sudo apt install nfs-kernel-server nfs-common

安装NFS客户端

所有的节点都得执行

sudo apt install nfs-common -y

创建目录

1
mkdir -p /data/storage/k8s/rocketmq

使用NFS作为StatefulSet持久化存储的操作记录,分别需要创建nfs-provisionerrbacstorageclassnfs-client-provisionerstatefulsetpod

创建nfs的rbac

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: nfs-provisioner
  namespace: sanjiang
---
kind: ClusterRole
apiVersion: rbac.authorization.k8s.io/v1
metadata:
   name: nfs-provisioner-runner
   namespace: sanjiang
rules:
   -  apiGroups: [""]
      resources: ["persistentvolumes"]
      verbs: ["get", "list", "watch", "create", "delete"]
   -  apiGroups: [""]
      resources: ["persistentvolumeclaims"]
      verbs: ["get", "list", "watch", "update"]
   -  apiGroups: ["storage.k8s.io"]
      resources: ["storageclasses"]
      verbs: ["get", "list", "watch"]
   -  apiGroups: [""]
      resources: ["events"]
      verbs: ["list","watch", "create", "update", "patch"]
   -  apiGroups: [""]
      resources: ["services", "endpoints"]
      verbs: ["get","create","list", "watch","update"]
   -  apiGroups: ["extensions"]
      resources: ["podsecuritypolicies"]
      resourceNames: ["nfs-provisioner"]
      verbs: ["use"]
   -  apiGroups: [""]
      resources: ["endpoints"]
      verbs: ["create", "delete", "get", "list", "watch", "patch", "update"]
---
kind: ClusterRoleBinding
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: run-nfs-provisioner
subjects:
  - kind: ServiceAccount
    name: nfs-provisioner
    namespace: sanjiang
roleRef:
  kind: ClusterRole
  name: nfs-provisioner-runner
  apiGroup: rbac.authorization.k8s.io

kubectl apply -f nfs-rbac.yaml

创建rocketmq集群的storageclass

1
2
3
4
5
6
7
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: rocketmq-nfs-storage
  namespace: sanjiang
provisioner: rocketmq/nfs
reclaimPolicy: Retain

kubectl apply -f rocketmq-nfs-class.yaml
查看创建情况
kubectl get sc -n sanjiang

创建rocketmq集群的nfs-client-provisioner

PROVISIONER_NAME的值一定要和StorageClass中的provisioner相等

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
apiVersion: apps/v1
kind: Deployment
metadata:
  name: rocketmq-nfs-client-provisioner
  namespace: sanjiang
spec:
  replicas: 1
  selector:
    matchLabels:
      app: rocketmq-nfs-client-provisioner
  strategy:
    type: Recreate
  template:
    metadata:
      labels:
        app: rocketmq-nfs-client-provisioner
    spec:
      serviceAccount: nfs-provisioner
      containers:
        - name: rocketmq-nfs-client-provisioner
          image: registry.cn-hangzhou.aliyuncs.com/open-ali/nfs-client-provisioner
          imagePullPolicy: IfNotPresent
          volumeMounts:
            - name: nfs-client-root
              mountPath:  /persistentvolumes
          env:
            - name: PROVISIONER_NAME
              value: rocketmq/nfs
            - name: NFS_SERVER
              value: 193.0.40.171 #nfs ip
            - name: NFS_PATH
              value: /data/storage/k8s/rocketmq
      volumes:
        - name: nfs-client-root
          nfs:
            server: 193.0.40.171 #nfs ip
            path: /data/storage/k8s/rocketmq

kubectl apply -f rocketmq-nfs.yml

k8s 部署

生成文件

broker-a-s.properties

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
brokerClusterName=rocketmq-cluster
brokerName=broker-a
brokerId=1
namesrvAddr=rocketmq-0.rocketmq:9876
defaultTopicQueueNums=4
autoCreateTopicEnable=true
autoCreateSubscriptionGroup=true
listenPort=20911
deleteWhen=04
fileReservedTime=120
mapedFileSizeCommitLog=1073741824
mapedFileSizeConsumeQueue=300000
diskMaxUsedSpaceRatio=88
storePathRootDir=/data/rocketmq/store
maxMessageSize=65536
brokerRole=SLAVE
flushDiskType=SYNC_FLUSH

broker-a.properties

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
brokerClusterName=rocketmq-cluster
brokerName=broker-a
brokerId=0
namesrvAddr=rocketmq-0.rocketmq:9876
defaultTopicQueueNums=4
autoCreateTopicEnable=true
autoCreateSubscriptionGroup=true
listenPort=20911
deleteWhen=04
fileReservedTime=120
mapedFileSizeCommitLog=1073741824
mapedFileSizeConsumeQueue=300000
diskMaxUsedSpaceRatio=88
storePathRootDir=/data/rocketmq/store
maxMessageSize=65536
brokerRole=MASTER

broker-b-s.properties

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
brokerClusterName=rocketmq-cluster
brokerName=broker-b
brokerId=1
namesrvAddr=rocketmq-0.rocketmq:9876
defaultTopicQueueNums=4
autoCreateTopicEnable=true
autoCreateSubscriptionGroup=true
listenPort=20911
deleteWhen=04
fileReservedTime=120
mapedFileSizeCommitLog=1073741824
mapedFileSizeConsumeQueue=300000
diskMaxUsedSpaceRatio=88
storePathRootDir=/data/rocketmq/store
maxMessageSize=65536
brokerRole=SLAVE
flushDiskType=SYNC_FLUSH

broker-b.properties

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
brokerClusterName=rocketmq-cluster
brokerName=broker-b
brokerId=0
namesrvAddr=rocketmq-0.rocketmq:9876
defaultTopicQueueNums=4
autoCreateTopicEnable=true
autoCreateSubscriptionGroup=true
listenPort=20911
deleteWhen=04
fileReservedTime=120
mapedFileSizeCommitLog=1073741824
mapedFileSizeConsumeQueue=300000
diskMaxUsedSpaceRatio=88
storePathRootDir=/data/rocketmq/store
maxMessageSize=65536
brokerRole=MASTER
flushDiskType=SYNC_FLUSH

broker-c-s.properties

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
brokerClusterName=rocketmq-cluster
brokerName=broker-c
brokerId=1
namesrvAddr=rocketmq-0.rocketmq:9876
defaultTopicQueueNums=4
autoCreateTopicEnable=true
autoCreateSubscriptionGroup=true
listenPort=20911
deleteWhen=04
fileReservedTime=120
mapedFileSizeCommitLog=1073741824
mapedFileSizeConsumeQueue=300000
diskMaxUsedSpaceRatio=88
storePathRootDir=/data/rocketmq/store
maxMessageSize=65536
brokerRole=SLAVE
flushDiskType=SYNC_FLUSH

broker-c.properties

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
brokerClusterName=rocketmq-cluster
brokerName=broker-c
brokerId=0
namesrvAddr=rocketmq-0.rocketmq:9876
defaultTopicQueueNums=4
autoCreateTopicEnable=true
autoCreateSubscriptionGroup=true
listenPort=20911
deleteWhen=04
fileReservedTime=120
mapedFileSizeCommitLog=1073741824
mapedFileSizeConsumeQueue=300000
diskMaxUsedSpaceRatio=88
storePathRootDir=/data/rocketmq/store
maxMessageSize=65536
brokerRole=MASTER
flushDiskType=SYNC_FLUSH

broker-d-s.properties

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
brokerClusterName=rocketmq-cluster
brokerName=broker-d
brokerId=1
namesrvAddr=rocketmq-0.rocketmq:9876
defaultTopicQueueNums=4
autoCreateTopicEnable=true
autoCreateSubscriptionGroup=true
listenPort=20911
deleteWhen=04
fileReservedTime=120
mapedFileSizeCommitLog=1073741824
mapedFileSizeConsumeQueue=300000
diskMaxUsedSpaceRatio=88
storePathRootDir=/data/rocketmq/store
maxMessageSize=65536
brokerRole=SLAVE
flushDiskType=SYNC_FLUSH

broker-d.properties

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
brokerClusterName=rocketmq-cluster
brokerName=broker-d
brokerId=0
namesrvAddr=rocketmq-0.rocketmq:9876
defaultTopicQueueNums=4
autoCreateTopicEnable=true
autoCreateSubscriptionGroup=true
listenPort=20911
deleteWhen=04
fileReservedTime=120
mapedFileSizeCommitLog=1073741824
mapedFileSizeConsumeQueue=300000
diskMaxUsedSpaceRatio=88
storePathRootDir=/data/rocketmq/store
maxMessageSize=65536
brokerRole=MASTER
flushDiskType=SYNC_FLUSH

运行命令

1
kubectl create cm rocketmq-config --from-file=broker-a.properties --from-file=broker-a-s.properties --from-file=broker-b.properties --from-file=broker-b-s.properties --from-file=broker-c.properties --from-file=broker-c-s.properties --from-file=broker-d.properties --from-file=broker-d-s.properties -n sanjiang

kubectl get cm -n sanjiang|grep rocketmq

创建配置文件

broker-a-s.yaml

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
apiVersion: v1
kind: Service
metadata:
  labels:
    app: broker-a-s
  name: broker-a-s
  namespace: sanjiang
spec:
  ports:
  - port: 20911
    targetPort: 20911
    name: broker-port
  selector:
    app: broker-a-s
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: broker-a-s
  namespace: sanjiang
spec:
  serviceName: broker-a-s
  replicas: 1
  selector:
    matchLabels:
      app: broker-a-s
  template:
    metadata:
     labels:
       app: broker-a-s
    spec:
      affinity:
        podAntiAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
            - labelSelector:
                matchExpressions:
                  - key: "app"
                    operator: In
                    values:
                      - broker-a-s
              topologyKey: "kubernetes.io/hostname"
      containers:
      - name: broker-a-s
        image: liuyi71sinacom/rocketmq-4.8.0
        imagePullPolicy: IfNotPresent
        command: ["sh","-c","mqbroker  -c /usr/local/rocketmq-4.8.0/conf/broker-a-s.properties"]
        env:
        - name: JAVA_OPT
          value: "-server -XX:ParallelGCThreads=1 -Xms1g -Xmx1g -Xmn512m"
          #value: "-XX:MaxRAMPercentage=80.0"
        volumeMounts:
          - mountPath: /root/logs
            name: rocketmq-data
            subPath: mq-brokeroptlogs
          - mountPath: /data/rocketmq
            name: rocketmq-data
            subPath: mq-brokeroptstore
          - name: broker-config
            mountPath: /usr/local/rocketmq-4.8.0/conf/broker-a-s.properties
            subPath: broker-a-s.properties
        lifecycle:
          postStart:
            exec:
              command: ["/bin/sh","-c","touch /tmp/health"]
        livenessProbe:
          exec:
            command: ["test","-e","/tmp/health"]
          initialDelaySeconds: 5
          timeoutSeconds: 5
          periodSeconds: 10
        readinessProbe:
          tcpSocket:
            port: 20911
          initialDelaySeconds: 15
          timeoutSeconds: 5
          periodSeconds: 20
      volumes:
      - name: broker-config
        configMap:
          name: rocketmq-config
          items:
          - key: broker-a-s.properties
            path: broker-a-s.properties
  volumeClaimTemplates:
  - metadata:
      name: rocketmq-data
      namespace: sanjiang
      annotations:
        volume.beta.kubernetes.io/storage-class: "rocketmq-nfs-storage"
    spec:
      accessModes:
        - ReadWriteMany
      resources:
        requests:
          storage: 2Gi
---
apiVersion: v1
kind: PersistentVolume
metadata:
  name:  broker-a-s-pv
  namespace: sanjiang
spec:
  accessModes:
    - ReadWriteMany
  capacity:
    storage: 2Gi
  persistentVolumeReclaimPolicy: Retain
  storageClassName: rocketmq-nfs-storage
  nfs:
    path: /data/storage/k8s/rocketmq/broker-a-s
    server: 193.0.40.171

broker-a.yaml

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
apiVersion: v1
kind: Service
metadata:
  labels:
    app: broker-a
  name: broker-a
  namespace: sanjiang
spec:
  ports:
  - port: 20911
    targetPort: 20911
    name: broker-port
  selector:
    app: broker-a
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: broker-a
  namespace: sanjiang
spec:
  serviceName: broker-a
  replicas: 1
  selector:
    matchLabels:
      app: broker-a
  template:
    metadata:
     labels:
       app: broker-a
    spec:
      affinity:
        podAntiAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
            - labelSelector:
                matchExpressions:
                  - key: "app"
                    operator: In
                    values:
                      - broker-a
              topologyKey: "kubernetes.io/hostname"
      containers:
      - name: broker-a
        image: liuyi71sinacom/rocketmq-4.8.0
        imagePullPolicy: IfNotPresent
        command: ["sh","-c","mqbroker  -c /usr/local/rocketmq-4.8.0/conf/broker-a.properties"]
        env:
        - name: JAVA_OPT
          value: "-server -XX:ParallelGCThreads=1 -Xms1g -Xmx1g -Xmn512m"
          #value: "-XX:MaxRAMPercentage=80.0"
        volumeMounts:
          - mountPath: /root/logs
            name: rocketmq-data
            subPath: mq-brokeroptlogs
          - mountPath: /data/rocketmq
            name: rocketmq-data
            subPath: mq-brokeroptstore
          - name: broker-config
            mountPath: /usr/local/rocketmq-4.8.0/conf/broker-a.properties
            subPath: broker-a.properties
        lifecycle:
          postStart:
            exec:
              command: ["/bin/sh","-c","touch /tmp/health"]
        livenessProbe:
          exec:
            command: ["test","-e","/tmp/health"]
          initialDelaySeconds: 5
          timeoutSeconds: 5
          periodSeconds: 10
        readinessProbe:
          tcpSocket:
            port: 20911
          initialDelaySeconds: 15
          timeoutSeconds: 5
          periodSeconds: 20
      volumes:
      - name: broker-config
        configMap:
          name: rocketmq-config
  volumeClaimTemplates:
  - metadata:
      name: rocketmq-data
      namespace: sanjiang
      annotations:
        volume.beta.kubernetes.io/storage-class: "rocketmq-nfs-storage"
    spec:
      accessModes:
        - ReadWriteMany
      resources:
        requests:
          storage: 2Gi
---
apiVersion: v1
kind: PersistentVolume
metadata:
  name:  broker-a-pv
  namespace: sanjiang
spec:
  accessModes:
    - ReadWriteMany
  capacity:
    storage: 2Gi
  persistentVolumeReclaimPolicy: Retain
  storageClassName: rocketmq-nfs-storage
  nfs:
    path: /data/storage/k8s/rocketmq/broker-a
    server: 193.0.40.171

broker-b-s.yaml

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
apiVersion: v1
kind: Service
metadata:
  labels:
    app: broker-b-s
  name: broker-b-s
  namespace: sanjiang
spec:
  ports:
  - port: 20911
    targetPort: 20911
    name: broker-port
  selector:
    app: broker-b-s
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: broker-b-s
  namespace: sanjiang
spec:
  serviceName: broker-b-s
  replicas: 1
  selector:
    matchLabels:
      app: broker-b-s
  template:
    metadata:
     labels:
       app: broker-b-s
    spec:
      affinity:
        podAntiAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
            - labelSelector:
                matchExpressions:
                  - key: "app"
                    operator: In
                    values:
                      - broker-b-s
              topologyKey: "kubernetes.io/hostname"
      containers:
      - name: broker-b-s
        image: liuyi71sinacom/rocketmq-4.8.0
        imagePullPolicy: IfNotPresent
        command: ["sh","-c","mqbroker -c /usr/local/rocketmq-4.8.0/conf/broker-b-s.properties"]
        env:
        - name: JAVA_OPT
          value: "-server -XX:ParallelGCThreads=1 -Xms1g -Xmx1g -Xmn512m"
          #value: "-XX:MaxRAMPercentage=80.0"
        volumeMounts:
          - mountPath: /root/logs
            name: rocketmq-data
            subPath: mq-brokeroptlogs
          - mountPath: /data/rocketmq
            name: rocketmq-data
            subPath: mq-brokeroptstore
          - name: broker-config
            mountPath: /usr/local/rocketmq-4.8.0/conf/broker-b-s.properties
            subPath: broker-b-s.properties
        lifecycle:
          postStart:
            exec:
              command: ["/bin/sh","-c","touch /tmp/health"]
        livenessProbe:
          exec:
            command: ["test","-e","/tmp/health"]
          initialDelaySeconds: 5
          timeoutSeconds: 5
          periodSeconds: 10
        readinessProbe:
          tcpSocket:
            port: 20911
          initialDelaySeconds: 15
          timeoutSeconds: 5
          periodSeconds: 20
      volumes:
      - name: broker-config
        configMap:
          name: rocketmq-config
          items:
          - key: broker-b-s.properties
            path: broker-b-s.properties
  volumeClaimTemplates:
  - metadata:
      name: rocketmq-data
      namespace: sanjiang
      annotations:
        volume.beta.kubernetes.io/storage-class: "rocketmq-nfs-storage"
    spec:
      accessModes:
        - ReadWriteMany
      resources:
        requests:
          storage: 2Gi
---
apiVersion: v1
kind: PersistentVolume
metadata:
  name:  broker-b-s-pv
  namespace: sanjiang
spec:
  accessModes:
    - ReadWriteMany
  capacity:
    storage: 2Gi
  persistentVolumeReclaimPolicy: Retain
  storageClassName: rocketmq-nfs-storage
  nfs:
    path: /data/storage/k8s/rocketmq/broker-b-s
    server: 193.0.40.171

broker-b.yaml

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
apiVersion: v1
kind: Service
metadata:
  labels:
    app: broker-b
  name: broker-b
  namespace: sanjiang
spec:
  ports:
  - port: 20911
    targetPort: 20911
    name: broker-port
  selector:
    app: broker-b
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: broker-b
  namespace: sanjiang
spec:
  serviceName: broker-b
  replicas: 1
  selector:
    matchLabels:
      app: broker-b
  template:
    metadata:
     labels:
       app: broker-b
    spec:
      affinity:
        podAntiAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
            - labelSelector:
                matchExpressions:
                  - key: "app"
                    operator: In
                    values:
                      - broker-b
              topologyKey: "kubernetes.io/hostname"
      containers:
      - name: broker-b
        image: liuyi71sinacom/rocketmq-4.8.0
        imagePullPolicy: IfNotPresent
        command: ["sh","-c","mqbroker  -c /usr/local/rocketmq-4.8.0/conf/broker-b.properties"]
        env:
        - name: JAVA_OPT
          value: "-server -XX:ParallelGCThreads=1 -Xms1g -Xmx1g -Xmn512m"
          #value: "-XX:MaxRAMPercentage=80.0"
        volumeMounts:
          - mountPath: /root/logs
            name: rocketmq-data
            subPath: mq-brokeroptlogs
          - mountPath: /data/rocketmq
            name: rocketmq-data
            subPath: mq-brokeroptstore
          - name: broker-config
            mountPath: /usr/local/rocketmq-4.8.0/conf/broker-b.properties
            subPath: broker-b.properties
        lifecycle:
          postStart:
            exec:
              command: ["/bin/sh","-c","touch /tmp/health"]
        livenessProbe:
          exec:
            command: ["test","-e","/tmp/health"]
          initialDelaySeconds: 5
          timeoutSeconds: 5
          periodSeconds: 10
        readinessProbe:
          tcpSocket:
            port: 20911
          initialDelaySeconds: 15
          timeoutSeconds: 5
          periodSeconds: 20
      volumes:
      - name: broker-config
        configMap:
          name: rocketmq-config
  volumeClaimTemplates:
  - metadata:
      name: rocketmq-data
      namespace: sanjiang
      annotations:
        volume.beta.kubernetes.io/storage-class: "rocketmq-nfs-storage"
    spec:
      accessModes:
        - ReadWriteMany
      resources:
        requests:
          storage: 2Gi
---
apiVersion: v1
kind: PersistentVolume
metadata:
  name:  broker-b-pv
  namespace: sanjiang
spec:
  accessModes:
    - ReadWriteMany
  capacity:
    storage: 2Gi
  persistentVolumeReclaimPolicy: Retain
  storageClassName: rocketmq-nfs-storage
  nfs:
    path: /data/storage/k8s/rocketmq/broker-b
    server: 193.0.40.171

broker-c-s.yaml

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
apiVersion: v1
kind: Service
metadata:
  labels:
    app: broker-c-s
  name: broker-c-s
  namespace: sanjiang
spec:
  ports:
  - port: 20911
    targetPort: 20911
    name: broker-port
  selector:
    app: broker-c-s
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: broker-c-s
  namespace: sanjiang
spec:
  serviceName: broker-c-s
  replicas: 1
  selector:
    matchLabels:
      app: broker-c-s
  template:
    metadata:
     labels:
       app: broker-c-s
    spec:
      affinity:
        podAntiAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
            - labelSelector:
                matchExpressions:
                  - key: "app"
                    operator: In
                    values:
                      - broker-c-s
              topologyKey: "kubernetes.io/hostname"
      containers:
      - name: broker-c-s
        image: liuyi71sinacom/rocketmq-4.8.0
        imagePullPolicy: IfNotPresent
        command: ["sh","-c","mqbroker  -c /usr/local/rocketmq-4.8.0/conf/broker-c-s.properties"]
        env:
        - name: JAVA_OPT
          value: "-server -XX:ParallelGCThreads=1 -Xms1g -Xmx1g -Xmn512m"
          #value: "-XX:MaxRAMPercentage=80.0"
        volumeMounts:
          - mountPath: /root/logs
            name: rocketmq-data
            subPath: mq-brokeroptlogs
          - mountPath: /data/rocketmq
            name: rocketmq-data
            subPath: mq-brokeroptstore
          - name: broker-config
            mountPath: /usr/local/rocketmq-4.8.0/conf/broker-c-s.properties
            subPath: broker-c-s.properties
        lifecycle:
          postStart:
            exec:
              command: ["/bin/sh","-c","touch /tmp/health"]
        livenessProbe:
          exec:
            command: ["test","-e","/tmp/health"]
          initialDelaySeconds: 5
          timeoutSeconds: 5
          periodSeconds: 10
        readinessProbe:
          tcpSocket:
            port: 20911
          initialDelaySeconds: 15
          timeoutSeconds: 5
          periodSeconds: 20
      volumes:
      - name: broker-config
        configMap:
          name: rocketmq-config
          items:
          - key: broker-c-s.properties
            path: broker-c-s.properties
  volumeClaimTemplates:
  - metadata:
      name: rocketmq-data
      namespace: sanjiang
      annotations:
        volume.beta.kubernetes.io/storage-class: "rocketmq-nfs-storage"
    spec:
      accessModes:
        - ReadWriteMany
      resources:
        requests:
          storage: 2Gi
---
apiVersion: v1
kind: PersistentVolume
metadata:
  name:  broker-c-s-pv
  namespace: sanjiang
spec:
  accessModes:
    - ReadWriteMany
  capacity:
    storage: 2Gi
  persistentVolumeReclaimPolicy: Retain
  storageClassName: rocketmq-nfs-storage
  nfs:
    path: /data/storage/k8s/rocketmq/broker-c-s
    server: 193.0.40.171

broker-c.yaml

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
apiVersion: v1
kind: Service
metadata:
  labels:
    app: broker-c
  name: broker-c
  namespace: sanjiang
spec:
  ports:
  - port: 20911
    targetPort: 20911
    name: broker-port
  selector:
    app: broker-c
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: broker-c
  namespace: sanjiang
spec:
  serviceName: broker-c
  replicas: 1
  selector:
    matchLabels:
      app: broker-c
  template:
    metadata:
     labels:
       app: broker-c
    spec:
      affinity:
        podAntiAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
            - labelSelector:
                matchExpressions:
                  - key: "app"
                    operator: In
                    values:
                      - broker-c
              topologyKey: "kubernetes.io/hostname"
      containers:
      - name: broker-c
        image: liuyi71sinacom/rocketmq-4.8.0
        imagePullPolicy: IfNotPresent
        command: ["sh","-c","mqbroker  -c /usr/local/rocketmq-4.8.0/conf/broker-c.properties"]
        env:
        - name: JAVA_OPT
          value: "-server -XX:ParallelGCThreads=1 -Xms1g -Xmx1g -Xmn512m"
          #value: "-XX:MaxRAMPercentage=80.0"
        volumeMounts:
          - mountPath: /root/logs
            name: rocketmq-data
            subPath: mq-brokeroptlogs
          - mountPath: /data/rocketmq
            name: rocketmq-data
            subPath: mq-brokeroptstore
          - name: broker-config
            mountPath: /usr/local/rocketmq-4.8.0/conf/broker-c.properties
            subPath: broker-c.properties
        lifecycle:
          postStart:
            exec:
              command: ["/bin/sh","-c","touch /tmp/health"]
        livenessProbe:
          exec:
            command: ["test","-e","/tmp/health"]
          initialDelaySeconds: 5
          timeoutSeconds: 5
          periodSeconds: 10
        readinessProbe:
          tcpSocket:
            port: 20911
          initialDelaySeconds: 15
          timeoutSeconds: 5
          periodSeconds: 20
      volumes:
      - name: broker-config
        configMap:
          name: rocketmq-config
  volumeClaimTemplates:
  - metadata:
      name: rocketmq-data
      namespace: sanjiang
      annotations:
        volume.beta.kubernetes.io/storage-class: "rocketmq-nfs-storage"
    spec:
      accessModes:
        - ReadWriteMany
      resources:
        requests:
          storage: 2Gi
---
apiVersion: v1
kind: PersistentVolume
metadata:
  name:  broker-c-pv
  namespace: sanjiang
spec:
  accessModes:
    - ReadWriteMany
  capacity:
    storage: 2Gi
  persistentVolumeReclaimPolicy: Retain
  storageClassName: rocketmq-nfs-storage
  nfs:
    path: /data/storage/k8s/rocketmq/broker-c
    server: 193.0.40.171

broker-d-s.yaml

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
apiVersion: v1
kind: Service
metadata:
  labels:
    app: broker-d-s
  name: broker-d-s
  namespace: sanjiang
spec:
  ports:
  - port: 20911
    targetPort: 20911
    name: broker-port
  selector:
    app: broker-d-s
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: broker-d-s
  namespace: sanjiang
spec:
  serviceName: broker-d-s
  replicas: 1
  selector:
    matchLabels:
      app: broker-d-s
  template:
    metadata:
     labels:
       app: broker-d-s
    spec:
      affinity:
        podAntiAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
            - labelSelector:
                matchExpressions:
                  - key: "app"
                    operator: In
                    values:
                      - broker-d-s
              topologyKey: "kubernetes.io/hostname"
      containers:
      - name: broker-d-s
        image: liuyi71sinacom/rocketmq-4.8.0
        imagePullPolicy: IfNotPresent
        command: ["sh","-c","mqbroker  -c /usr/local/rocketmq-4.8.0/conf/broker-d-s.properties"]
        env:
        - name: JAVA_OPT
          value: "-server -XX:ParallelGCThreads=1 -Xms1g -Xmx1g -Xmn512m"
          #value: "-XX:MaxRAMPercentage=80.0"
        volumeMounts:
          - mountPath: /root/logs
            name: rocketmq-data
            subPath: mq-brokeroptlogs
          - mountPath: /data/rocketmq
            name: rocketmq-data
            subPath: mq-brokeroptstore
          - name: broker-config
            mountPath: /usr/local/rocketmq-4.8.0/conf/broker-d-s.properties
            subPath: broker-d-s.properties
        lifecycle:
          postStart:
            exec:
              command: ["/bin/sh","-c","touch /tmp/health"]
        livenessProbe:
          exec:
            command: ["test","-e","/tmp/health"]
          initialDelaySeconds: 5
          timeoutSeconds: 5
          periodSeconds: 10
        readinessProbe:
          tcpSocket:
            port: 20911
          initialDelaySeconds: 15
          timeoutSeconds: 5
          periodSeconds: 20
      volumes:
      - name: broker-config
        configMap:
          name: rocketmq-config
          items:
          - key: broker-d-s.properties
            path: broker-d-s.properties
  volumeClaimTemplates:
  - metadata:
      name: rocketmq-data
      namespace: sanjiang
      annotations:
        volume.beta.kubernetes.io/storage-class: "rocketmq-nfs-storage"
    spec:
      accessModes:
        - ReadWriteMany
      resources:
        requests:
          storage: 2Gi
---
apiVersion: v1
kind: PersistentVolume
metadata:
  name:  broker-d-s-pv
  namespace: sanjiang
spec:
  accessModes:
    - ReadWriteMany
  capacity:
    storage: 2Gi
  persistentVolumeReclaimPolicy: Retain
  storageClassName: rocketmq-nfs-storage
  nfs:
    path: /data/storage/k8s/rocketmq/broker-d-s
    server: 193.0.40.171

broker-d.yaml

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
apiVersion: v1
kind: Service
metadata:
  labels:
    app: broker-d
  name: broker-d
  namespace: sanjiang
spec:
  ports:
  - port: 20911
    targetPort: 20911
    name: broker-port
  selector:
    app: broker-d
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: broker-d
  namespace: sanjiang
spec:
  serviceName: broker-d
  replicas: 1
  selector:
    matchLabels:
      app: broker-d
  template:
    metadata:
     labels:
       app: broker-d
    spec:
      affinity:
        podAntiAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
            - labelSelector:
                matchExpressions:
                  - key: "app"
                    operator: In
                    values:
                      - broker-d
              topologyKey: "kubernetes.io/hostname"
      containers:
      - name: broker-d
        image: liuyi71sinacom/rocketmq-4.8.0
        imagePullPolicy: IfNotPresent
        command: ["sh","-c","mqbroker  -c /usr/local/rocketmq-4.8.0/conf/broker-d.properties"]
        env:
        - name: JAVA_OPT
          value: "-server -XX:ParallelGCThreads=1 -Xms1g -Xmx1g -Xmn512m"
          #value: "-XX:MaxRAMPercentage=80.0"
        volumeMounts:
          - mountPath: /root/logs
            name: rocketmq-data
            subPath: mq-brokeroptlogs
          - mountPath: /data/rocketmq
            name: rocketmq-data
            subPath: mq-brokeroptstore
          - name: broker-config
            mountPath: /usr/local/rocketmq-4.8.0/conf/broker-d.properties
            subPath: broker-d.properties
        lifecycle:
          postStart:
            exec:
              command: ["/bin/sh","-c","touch /tmp/health"]
        livenessProbe:
          exec:
            command: ["test","-e","/tmp/health"]
          initialDelaySeconds: 5
          timeoutSeconds: 5
          periodSeconds: 10
        readinessProbe:
          tcpSocket:
            port: 20911
          initialDelaySeconds: 15
          timeoutSeconds: 5
          periodSeconds: 20
      volumes:
      - name: broker-config
        configMap:
          name: rocketmq-config
  volumeClaimTemplates:
  - metadata:
      name: rocketmq-data
      namespace: sanjiang
      annotations:
        volume.beta.kubernetes.io/storage-class: "rocketmq-nfs-storage"
    spec:
      accessModes:
        - ReadWriteMany
      resources:
        requests:
          storage: 2Gi
---
apiVersion: v1
kind: PersistentVolume
metadata:
  name:  broker-d-pv
  namespace: sanjiang
spec:
  accessModes:
    - ReadWriteMany
  capacity:
    storage: 2Gi
  persistentVolumeReclaimPolicy: Retain
  storageClassName: rocketmq-nfs-storage
  nfs:
    path: /data/storage/k8s/rocketmq/broker-d
    server: 193.0.40.171

console.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
apiVersion: apps/v1
kind: Deployment
metadata:
  creationTimestamp: null
  labels:
    app: console
  name: console
  namespace: sanjiang
spec:
  replicas: 1
  selector:
    matchLabels:
      app: console
  strategy: {}
  template:
    metadata:
      creationTimestamp: null
      labels:
        app: console
    spec:
      containers:
      - image: styletang/rocketmq-console-ng
        name: rocketmq-console-ng
        env:
        - name: JAVA_OPTS
          value: "-Drocketmq.namesrv.addr=rocketmq:9876 -Dcom.rocketmq.sendMessageWithVIPChannel=false"
        resources: {}
status: {}
---
apiVersion: v1
kind: Service
metadata:
  creationTimestamp: null
  labels:
    app: console
  name: console
  namespace: sanjiang
spec:
  ports:
  - port: 8080
    protocol: TCP
    targetPort: 8080
    nodePort: 32080
  selector:
    app: console
  type: NodePort

namesrv.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
apiVersion: v1
kind: Service
metadata:
  labels:
    app: mq-namesrv
  name: rocketmq
  namespace: sanjiang
spec:
  ports:
  - port: 9876
    targetPort: 9876
    nodePort: 32076
    name: namesrv-port
  selector:
    app: mq-namesrv
  type: NodePort
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: rocketmq
  namespace: sanjiang
spec:
  serviceName: rocketmq
  replicas: 1
  selector:
    matchLabels:
      app: mq-namesrv
  template:
    metadata:
     labels:
       app: mq-namesrv
    spec:
      affinity:
        podAntiAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
            - labelSelector:
                matchExpressions:
                  - key: "app"
                    operator: In
                    values:
                      - mq-namesrv
              topologyKey: "kubernetes.io/hostname"
      containers:
      - name: mq-namesrv
        image: liuyi71sinacom/rocketmq-4.8.0
        imagePullPolicy: IfNotPresent
        command: ["sh","/usr/local/rocketmq-4.8.0/bin/mqnamesrv"]
        ports:
        - containerPort: 9876
          protocol: TCP
        env:
        - name: JAVA_OPT
          value: "-server -XX:ParallelGCThreads=1 -Xms1g -Xmx1g -Xmn512m"
          #value: "-XX:MaxRAMPercentage=80.0"
        lifecycle:
          postStart:
            exec:
              command: ["/bin/sh","-c","touch /tmp/health"]
        livenessProbe:
          exec:
            command: ["test","-e","/tmp/health"]
          initialDelaySeconds: 5
          timeoutSeconds: 5
          periodSeconds: 10
        readinessProbe:
          tcpSocket:
            port: 9876
          initialDelaySeconds: 15
          timeoutSeconds: 5
          periodSeconds: 20

ingress.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
apiVersion: extensions/v1beta1
kind: Ingress
metadata:
  name: rocketmq
  namespace: sanjiang
spec:
 ingressClassName: nginx
 rules:
 - host: mq.sj.com
   http:
     paths:
     - path: /
       backend:
         serviceName: console
         servicePort: 8080

部署服务

1
kubectl apply -f .
